Scenes from the Polyclinic: syndesmosis

2002 02 06 16 20 34 706
By Dr. Julia Crim

SALT LAKE CITY – Interacting with physicians from around the world is one of the main reasons why radiologists like working at the Olympic Polyclinic. In most cases, the coaches and team doctors review the MRI with the radiologist.

Sometimes there is a language barrier, however, and no interpreter was available in this case. Fortunately, the English-speaking radiologist and the foreign team doctor soon found out they had an important word in common: syndesmosis. Much hand waving and pointing at images followed, and the two were able to discuss this syndesmosis sprain.

2002 02 19 19 27 46 706
Mortise view of the ankle; width of the mortise is normal.


2002 02 19 19 28 28 706 Axial fast spin echo inversion recovery (FSEIR) through the distal leg shows the proximal extent of the syndesmosis tear, with a focal defect in the interosseous membrane (arrow).


2002 02 19 19 29 08 706
Axial FSEIR at the tibial plafond shows rupture of the anterior and posterior tibiofibular ligaments, and the interosseous membrane (arrow).


2002 02 19 19 29 44 706
Coronal FSEIR shows fluid (short arrow) at the anterolateral aspect of the ankle related to the syndesmosis sprain. It also demonstrates sprain of the deltoid ligament (long arrow).


By Dr. Julia Crim
AuntMinnie.com contributing writer
February 20, 2002

Thursday: Midfoot fracture dislocation.

Dr. Crim is chief of musculoskeletal imaging at the Olympic Polyclinic.
